As you’d expect for a bike at this level, nothing has been left to chance, from the shrouded drag reducing dropouts or virtually perfect aerodynamic profile of the seat tube that feature in all Oltre models. And the results speak for themselves – a saving of 17.1 Watts compared to the Oltre XR4 at 50kph!
There’s little point in optimising a bike in isolation from the rider. When considering aerodynamic drag – and the new Oltre is, above all, an aerodynamically optimised bike – the rider presents by far the most significant ‘object’ within the bike-plus-rider system. So the the new Oltre achieves two things aerodynamically – it optimizes both the contribution of the bike, and of the bike and rider together. All while delivering the things that the Oltre has always been famous for: responsiveness, balanced handling, and smoothness.
FRAMESET
FRAME - Oltre Comp, carbon, disc brakes, electronic and mechanical shifting compatible, internal cable routing 1.5-1.5 headset, BB-PressFit 86,5x41, flat mount brakes, thru axle 12x142mm sizes 47-50-53-55-57-59cm
FORK - Full Carbon aero, disc brakes, integrated head 1,5", thru axle 12x100mm, compatible with 700x30 tire
HEADSET - Fsa TH-073E ACB 1.5" 51.8x40x8
DRIVETRAIN
SHIFTERS - Shimano Ultegra Di2 hydraulic disc brake for road, ST-R8170, BR-R8170, for 160mm rotor
REAR DERAILLEUR - Shimano Ultegra Di2 12sp, RD-R8150
FRONT DERAILLEUR - Shimano Ultegra Di2 12sp, FD-R8150
CRANKSET - Shimano, Ultegra 12sp, FC-R8100, Ultegra hollowtech 2, for rear 12- speed, 50x34T, Crank Length: 170mm-47/54cm, 172.5mm-55/59cm
BOTTOM BRACKET - Shimano, SM-BB72-41B, press fit for road, bearing, inner cover
CHAIN - Shimano, Ultegra 12 sp, CN-M8100
BRAKES
BRAKES - Shimano BR-R8170 Hydraulic disc brake, included in the shifter
ROTOR - Shimano center lock type w/Ice Tech, 160mm front rear
WHEELS
WHEELS - Velomann Carbon V50R 50mm profile, 700x21c, HG body, UD carbon fiber, tubeless ready and clincher, Internal width: 21 mm, weight per set: 1.630g
TIRE - Pirelli P7, 700 x 28c, 60TPI
COCKPIT
STEM - Velomann Aero stem, material alloy, Oversize, 1.1/8", size: 90mm-47/50cm, 100mm-53cm, 110mm-55/57cm, 120mm-59cm
HANDLEBAR - Velomann Aero Compact handlebar, alloy diam. 31,8mm, reach 74mm, drop 116mm, for fully internal cable routing Size: 400mm-47~53cm, 420mm-55~59cm
GRIPS - Velo soft Microfiber tape, black
SADDLE
SEATPOST - Oltre Full Carbon Aero special dimension seatpost, 20mm offset, length: 280mm-47cm, 300mm-50/53cm, 350mm-55/59cm
SADDLE - Velomann Mitora139 Hyper, open flow, carbon rails, carbon-reinforced nylon, Large 139mm Lenght 250mm
